Methodology

Carbon dioxide (CO₂) emissions, expressed as kilograms of CO₂-equivalents [CO₂eq], are the product of two main factors :

C = Carbon Intensity of the electricity consumed for computation: quantified as g of CO₂ emitted per kilowatt-hour of electricity.

E = Energy Consumed by the computational infrastructure: quantified as kilowatt-hours.

Carbon dioxide emissions (CO₂eq) can then be calculated as C * E

Carbon Intensity

Carbon Intensity of the consumed electricity is calculated as a weighted average of the emissions from the different energy sources that are used to generate electricity, including fossil fuels and renewables. In this toolkit, the fossil fuels coal, petroleum, and natural gas are associated with specific carbon intensities: a known amount of carbon dioxide is emitted for each kilowatt-hour of electricity generated. Renewable or low-carbon fuels include solar power, hydroelectricity, biomass, geothermal, and more. The nearby energy grid contains a mixture of fossil fuels and low-carbon energy sources, called the Energy Mix. Based on the mix of energy sources in the local grid, the Carbon Intensity of the electricity consumed can be computed.

Grid Energy Mix

When available, CodeCarbon uses global carbon intensity of electricity per cloud provider ( here ) or per country ( here ).

If we don’t have the global carbon intensity or electricity of a country, but we have its electricity mix, we used to compute the carbon intensity of electricity using this table:

Carbon Intensity Across Energy Sources

Energy Source

Carbon Intensity (kg/MWh)

Coal

995

Petroleum

816

Natural Gas

743

Geothermal

38

Hydroelectricity

26

Nuclear

29

Solar

48

Wind

26

Sources:

Then, for example, if the Energy Mix of the Grid Electricity is 25% Coal, 35% Petroleum, 26% Natural Gas and 14% Nuclear:

Net Carbon Intensity = 0.25 * 995 + 0.35 * 816 + 0.26 * 743 + 0.14 * 29 = 731.59 kgCO₂/kWh

But it doesn’t append anymore because Our World in Data now provides the global carbon intensity of electricity per country ( source ). Some countries is missing data for last year, so we use the previous year data available.

If ever we have neither the global carbon intensity of a country nor it’s electricity mix, we apply a world average of 475 gCO2.eq/KWh ( source ).

As you can see, we try to be as accurate as possible in estimating carbon intensity of electricity. Still there is room for improvement and all contributions are welcome.

Power Usage

Power supply to the underlying hardware is tracked at frequent time intervals. This is a configurable parameter measure_power_secs, with default value 15 seconds, that can be passed when instantiating the emissions’ tracker.

Currently, the package supports the following hardware infrastructure.

GPU

Tracks Nvidia GPUs energy consumption using pynvml library (installed with the package).

RAM

CodeCarbon v2 uses a 3 Watts for 8 GB ratio source .

But this is not a good measure because it doesn’t take into account the number of RAM slots used in the machine, that really drive the power consumption, not the amount of RAM. For example, in servers you could have thousands of GB of RAM but the power consumption would not be proportional to the amount of memory used, but to the number of memory modules used.

Old machine could use 2 Mb memory stick, where modern servers will use 128 Mb memory stick.

So, in CodeCarbon v3 we switch to using 5 Watts for each RAM slot. The energy consumption is calculated as follows: .. code-block:: text

RAM Power Consumption = 5 Watts * Number of RAM slots used

But getting the number of RAM slots used is not possible as you need root access to get the number of RAM slots used. So we use an heuristic based on the RAM size.

For example keep a minimum of 2 modules. Except for ARM CPU like rapsberry pi where we will consider a 3W constant. Then consider the max RAM per module is 128GB and that RAM module only exist in power of 2 (2, 4, 8, 16, 32, 64, 128). So we can estimate the power consumption of the RAM by the number of modules used.

  • For ARM CPUs (like Raspberry Pi), a constant 3W will be used as the minimum power

  • Base power per DIMM is 5W for x86 systems and 1.5W for ARM systems

  • For standard systems (up to 4 DIMMs): linear scaling at full power per DIMM

  • For medium systems (5-8 DIMMs): decreasing efficiency (90% power per additional DIMM)

  • For large systems (9-16 DIMMs): further reduced efficiency (80% power per additional DIMM)

  • For very large systems (17+ DIMMs): highest efficiency (70% power per additional DIMM)

  • Ensures at least 10W for x86 systems (assuming 2 DIMMs at minimum)

  • Ensures at least 3W for ARM systems

Example Power Estimates:

  • Small laptop (8GB RAM): ~10W (2 DIMMs at 5W each)

  • Desktop (32GB RAM): ~20W (4 DIMMs at 5W each)

  • Desktop (64GB RAM): ~20W (4 DIMMs at 5W each), the same as 32GB

  • Small server (128GB RAM): ~40W (8 DIMMs with efficiency scaling)

  • Large server (1TB RAM): ~40W (using 8x128GB DIMMs with high efficiency scaling)

This approach significantly improves the accuracy for large servers by recognizing that RAM power consumption doesn’t scale linearly with capacity, but rather with the number of physical modules. Since we don’t have direct access to the actual DIMM configuration, this heuristic provides a more reasonable estimate than the previous linear model.

If you know the exact RAM power consumption of your system, then provide it using the force_ram_power parameter, which will override the automatic estimation.

For example, in a Ubuntu machine, you can get the number of RAM slots used with the following command:

sudo lshw -C memory -short | grep DIMM

/0/37/0                                    memory         4GiB DIMM DDR4 Synchrone Unbuffered (Unregistered) 2400 MHz (0,4 ns)
/0/37/1                                    memory         4GiB DIMM DDR4 Synchrone Unbuffered (Unregistered) 2400 MHz (0,4 ns)
/0/37/2                                    memory         4GiB DIMM DDR4 Synchrone Unbuffered (Unregistered) 2400 MHz (0,4 ns)
/0/37/3                                    memory         4GiB DIMM DDR4 Synchrone Unbuffered (Unregistered) 2400 MHz (0,4 ns)

Here we count 4 RAM slots used, so the power consumption will be 4 x 5 = 20 Watts, just add force_ram_power=20 to the init of CodeCarbon.

CPU

  • On Windows or Mac (Intel)

Tracks Intel processors energy consumption using the Intel Power Gadget. You need to install it yourself from this source . But has been discontinued. There is a discussion about it on github issues #457.

  • Apple Silicon Chips (M1, M2)

Apple Silicon Chips contain both the CPU and the GPU.

Codecarbon tracks Apple Silicon Chip energy consumption using powermetrics. It should be available natively on any mac. However, this tool is only usable with sudo rights and to our current knowledge, there are no other options to track the energy consumption of the Apple Silicon Chip without administrative rights (if you know of any solution for this do not hesitate and open an issue with your proposed solution).

To give sudo rights without having to enter a password each time, you can modify the sudoers file with the following command:

sudo visudo

Then add the following line at the end of the file:

username ALL = (root) NOPASSWD: /usr/bin/powermetrics

If you do not want to give sudo rights to your user, then CodeCarbon will fall back to constant mode to measure CPU energy consumption.

  • On Linux

Tracks Intel and AMD processor energy consumption from Intel RAPL files at /sys/class/powercap/intel-rapl/subsystem ( reference ). All CPUs listed in this directory will be tracked.

Note: The Power Consumption will be tracked only if the RAPL files exist at the above-mentioned path and if the user has the necessary permissions to read them.

CPU hardware

The CPU die is the processing unit itself. It’s a piece of semiconductor that has been sculpted/etched/deposited by various manufacturing processes into a net of logic blocks that do stuff that makes computing possible1. The processor package is what you get when you buy a single processor. It contains one or more dies, plastic/ceramic housing for dies and gold-plated contacts that match those on your motherboard.

In Linux kernel, energy_uj is a current energy counter in micro joules. It is used to measure CPU core’s energy consumption.

Micro joules is then converted in kWh, with formulas kWh=energy * 10 ** (-6) * 2.77778e-7

For example, on a laptop with Intel(R) Core(TM) i7-7600U, Code Carbon will read two files : /sys/class/powercap/intel-rapl/intel-rapl:1/energy_uj and /sys/class/powercap/intel-rapl/intel-rapl:0/energy_uj

RAPL Metrics

RAPL stand for Running Average Power Limit, it is a feature of processors (CPU) that provide the energy consumption of the processor.

See https://blog.chih.me/read-cpu-power-with-RAPL.html for more information.

Despite the name Intel RAPL, it support AMD processors since kernel 5.8.

It is some files in /sys/class/powercap/intel-rapl/subsystem/ that give the energy consumption of the CPU, and sometime RAM. There are folder for each domain, and in each folder there are a file name with the name of the domain and a energy_uj for the amount of energy in micro-joules.

The drawback of RAPL is that not every CPU use it the same way. We focus on the package domain, but some CPU have more domain like core, uncore, dram, psys, gpu, psys and psys-io.

For example : - Intel put all the physical cores consumption in core and the package include core. - For AMD, core have very low energy, so we don’t know if it is included in the package or not.

Our friend from Scaphandre, a tool to monitor energy consumption, have a good article about RAPL https://hubblo-org.github.io/scaphandre-documentation/explanations/rapl-domains.html and also a discussion with good references: https://github.com/hubblo-org/scaphandre/issues/116#issuecomment-854453231 and point out that this topic is not well documented.

https://user-images.githubusercontent.com/894892/120764898-ecf07280-c518-11eb-9155-92780cabcf52.png Source :“RAPL in Action: Experiences in Using RAPL for Power Measurements,” (K. N. Khan, M. Hirki, T. Niemi, J. K. Nurminen, and Z. Ou, ACM Trans. Model. Perform. Eval. Comput. Syst., vol. 3, no. 2, pp. 1–26, Apr. 2018, doi: 10.1145/3177754.)

Metric comparison

Desktop computer with AMD Ryzen Threadripper 1950X 16-Core (32 threads) Processor. Power plug measure when idle (10% CPU): 125 W package-0-die-0 : 68 W package-0-die-1 : 68 W CodeCarbon : 137 W

Power plug measure when loaded (100% CPU): 256 W - 125W in idle = 131 W CorWatt PkgWatt

133.13 169.82 7.54 169.82

CodeCarbon : 330 W package-0-die-0 : 166 W package-0-die-1 : 166 W

RAPL: 234 sec. Joule Counter Range, at 280 Watts

CPU metrics priority

CodeCarbon will first try to read the energy consumption of the CPU from low level interface like RAPL or powermetrics. If none of the tracking tools are available, CodeCarbon will be switched to a fallback mode:

  • It will first detect which CPU hardware is currently in use, and then map it to a data source listing 2000+ Intel and AMD CPUs and their corresponding thermal design powers (TDPs).

  • If the CPU is not found in the data source, a global constant will be applied.

  • If psutil is available, CodeCarbon will try to estimate the energy consumption from the TDP and the CPU load.

  • CodeCarbon assumes that 50% of the TDP will be the average power consumption to make this approximation.

Here is a drawing of the fallback mode:

CPU Fallback

The code doing this is available in codecarbon/core/resource_tracker.py.

The net Energy Used is the net power supply consumed during the compute time, measured as kWh.

We compute energy consumption as the product of the power consumed and the time the power was consumed for. The formula is: Energy = Power * Time

References

Energy Usage Reports: Environmental awareness as part of algorithmic accountability

How CodeCarbon Works

CodeCarbon uses a scheduler that, by default, calls for a measure every 15 seconds, so it has no significant overhead.

The measure itself is fast and CodeCarbon is designed to be as light as possible with a small memory footprint.

The scheduler is started when the first start method is called and stopped when stop method is called.

Estimation of Equivalent Usage Emissions

The CodeCarbon dashboard provides equivalent emissions and energy usage comparisons to help users better understand the carbon impact of their activities. These comparisons are based on the following assumptions:

Car Usage

  • Emission factor: 0.12 kgCO₂ per kilometer driven.

  • This value is derived from the average emissions of a European passenger car under normal driving conditions.

Source : European Environment Agency

TV Usage

  • Energy consumption: 138 Wh per day based on average use.

  • This assumes: - An average daily usage of 6.5 hours. - A modern television with a power consumption of approximately 21.2 W per hour.

Source : The French Agency for Ecological Transition

US Citizen Weekly Emissions

  • Annual emissions: 13.3 tons of CO₂ equivalent per year for an average US citizen.

  • Weekly emissions: This value is divided by the 52 weeks in a year to estimate weekly emissions:

\[\text{Weekly Emissions} = \frac{\text{Annual Emissions (tons)}}{52}\]
\[\text{Weekly Emissions} = \frac{13.3}{52} \approx 0.256 \, \text{tons of CO₂ equivalent per week.}\]

Source : IEA CO2 total emissions per capita by region, 2000-2023

Calculation Formula

The equivalent emissions are calculated using this formula:

\[\text{Equivalent Emissions} = \frac{\text{Total Emissions (kgCO₂)}}{\text{Emission Factor (kgCO₂/unit)}}\]

For example:

  • Car Usage: 1 kWh of energy consumption is approximately equivalent to: - 8.33 kilometers driven by a car (1 ÷ 0.12). - 11.9 hours of TV usage (1 ÷ 0.084), if emissions are considered.

  • US Citizen Emissions: - 1 kWh of energy consumption can be compared to a fraction of the average weekly emissions of a US citizen:

\[\text{US Citizen Equivalent} = \frac{\text{Total Emissions (tons)}}{0.256}\]

These estimates are approximate and subject to regional variations in: - Grid emissions intensity. - Vehicle efficiencies.

Source Code

The emission factors used are defined in the CodeCarbon source code. They are based on publicly available data and general assumptions.
